Standard Measurement Range | 300kg, 500kg, 1t, 2t, 3t, 4t, 5t, 10t, 15t, 20t |
---|---|
Output Signal | 1-1.5 mV/V |
Accuracy (combined LRH) | Check data sheet |
Creep | ±0.05% FS / 30min |
Overload Rating | 120% FS |
Zero unbalance | ±2% FS |
Protection Level | No |
Compensated Temp. Range | -10 to 60°C |
Operating Temp. Range | -20 to +80°C |
Temp. Coefficient of Zero | 0.05% FS /10°C |
Temp. Coefficient of Span | 0.05% FS /10°C |
Input Resistance | 750±10Ω |
Output Resistance | 700±3Ω |
Insulation resistance | ≥5000MΩ @ 50VDC |
Electric Connection | 3m cable |
Wide Load Measurement Range of 0.3 – 20t
High accuracy and durability
Compact and robust construction
Bolt performance monitoring
Pressure measurement for switches
Pressing machines
Force detection in assembly of automobiles
Pressure measurement for hot and cold lamination
Force measurement in robotic arms
