    • Technical Specification
    • Features
    • Applications
    TechnologyPiezo resistive
    TypeDifferential Pressure Sensor
    Standard Measurement Range (bar)0.1, 0.2, 0.5, 1, 5, 10, 20, 35
    Purpose and ApplicationGeneral Purpose
    Accuracy (combined LRH)0.05% FS, 0.1% FS, 0.25% FS
    Output Signal4-20mA, 0-2.5V, 0-5VDC, 0-10VDC, 1-5VDC
    Pressure ReferenceDif.: Differential
    Process ConnectionG1/4(¼” BSPP male), R1/4(¼” BSPT male) , NPT1/4(¼” NPT male) , Others
    Electric Connection3m cable, DIN 43650 connector, Others
    Protection LevelIP65, IP68 (with cable connection)
    Overload Rating200%
    Long Term Stability<0.2% FS/year
    Diaphragm MaterialStainless Steel 316L, Other
    Compensated Temp. Range0 to 70°C
    Operating Temp. Range-20 to +80°C
    Temp. Coefficient of Zero0.03% FS /°C
    Temp. Coefficient of Span0.03% FS /°C
    Input ResistanceN/A
    Output ResistanceN/A
    Insulation resistance100MΩ @ 50VDC
    Zero offsetNo
    • High Measuring Accuracy
    • Differential Pressure Measurement
    • Range of 0.1 to 35bar
    • Compact and Rugged Model
    • Wide Range of Media Compatibility
    • Low Static and Thermal Errors
    • Hydraulic systems
    • Pump controls
    • Pneumatic systems
    • Manufacturing process controls
    • Fire control systems
    • Manufacturing automation
    • Hydrology research
    • Hydro balancing systems
