Technology | MEMS |
---|---|
Type | Pressure Transducer |
Standard Measurement Range (bar) | 0.1, 0.2, 0.5, 1, 2, 5, 10, 20, 50, 100, 200, 400, 600, 800, 1000 |
Purpose and Application | High Frequency, Compact Size / Miniature |
Accuracy (combined LRH) | 0.25% FS, 0.5% FS |
Output Signal | ~ 70mV |
Pressure Reference | Sealed to 1 bar, Vented Gauge (0 at atmospheric pressure) |
Process Connection | G1/2(½” BSPP male), M20x1.5, Others |
Electric Connection | 3m cable, DIN 43650 connector, Others |
Protection Level | IP65, IP68 (with cable connection) |
Overload Rating | 200% |
Long Term Stability | <0.2% FS/year |
Diaphragm Material | Other |
Compensated Temp. Range | 0 to 70°C |
Operating Temp. Range | -10 to +80°C |
Temp. Coefficient of Zero | 0.03% FS /°C |
Temp. Coefficient of Span | 0.03% FS /°C |
Input Resistance | 1-6kΩ |
Output Resistance | 2-6kΩ |
Insulation resistance | 100MΩ @ 50VDC |
Zero offset | ≤ ±2mV |
